Wheel hub bearing grinding for raceway of inner flange

The wheel hub bearing flange grinding is the most refined technology for raceway of wheel hub bearings , processing object include the second generation and the third generation of wheel hub bearings flange, this model can achieve the higher tolerance accuracy and better surface finish of wheel hub bearing inner rings. and has higher precision, higher stability, higher efficiency, widely used in car and truck and automotive production industry.


Main Specification

The wheel hub bearing flange grinding is adopted advanced control system, electronic, pneumatic, hydraulic, automatic online detection integration function, replaceable fixture technology and improvement device with online measuring and detection work piece processing status, automatic loading and unloading functions, realize the higher accuracy grinding for raceway of wheel hub bearings of inner flange.

The grinding machine main function unit were adopted the excellent function design, such as Siemens controller, electromagnetic center less chuck unit, the spindle of work piece head is setting the NSK or TNT bearings for improving the stability of spindle, and dresser unit is used the diamond wheel dressing,and apply the strong loading and unloading arm for ensure the good profile surface of hub flange, or use the flame type robot(optional), all modern function and units can achieve the highest-level demand from automotive industries, and the x, y, z axial slides lubrication by the automatic grease oil, that ensure the motion unit has the longest working life. and much more functions that we can set balancing system to increase the grinding processing accuracy.

Processing Range

Tech Parameter
